Performance Basic
Price on request

Characteristics

Number of animals
2 Horses
Family
Performance family, 7200 kg
Number of sleeping places
You are looking for a spacious, economical vehicle for transporting two horses in longitudinal position, combined with maximum payload? In this case, the Performance Basic is the perfect companion for you.

Technical data

Base
Number of animals Number of animals
2 Horses
Apartments Apartments
Living cabin 130 cm
Bathroom Bathroom
Weight
Total weight Total weight
7200 kg
Payload Payload
2600 kg
External dimensions
Total length Total length
7450 mm
Total width Total width
2340 mm
Total height Total height
3350 mm
Internal dimensions
Interior length Interior length
5000 mm
Interior width Interior width
2300 mm
Interior height Interior height
2500 mm

Standard features

Body

  • Body general
    • Alcove
    • Aluminum corner profiles, rounded
    • Loading ramp (side) with rubber with special step bars and side stop
    • Roof skylight, big version, incl. closing support
    • Insulated sandwich roof 50 mm thick (GRP)
    • Roof spoiler on tailgate integrated brake and clearance lights (LED)
    • Roof ventilator switchable from the drivers cabinet
    • Windows (2x) vertically sliding 450x600mm with integral window grille
    • Horizontal sliding window in left side panel 450x300mm
    • Aluminum profile base on hot galvanized frame
  • Body Horse department
    • Barrier belt in front of the loading flap
    • Partition wall alum. (L) with PVC panel and integrated head section
    • Tethering rings (2 per horse)
    • 2 breast bars with MSS
    • Feeding troughs, plastic (1 per horse) for hanging
    • Rubber floor, glued and sealed
    • hay net hooks ( 1 per horse)
    • LED-Light in horse area
    • Kick protection in the back of the horse area
    • Side padding for partition wall and left side wall
  • Tack room
    • LED-Light in tack room (there switchable)
    • Shelve on the left
    • Saddle-rack ( 2 x )
    • Tack room, about 900x2300 mm
    • Mirror at door (2x)
    • Snaffle hooks (4x )
    • Lockable door in the rear (side) to the saddle room and folding steps
    • Forced ventilation

Chassis

  • Chassis
    • Passenger double seat bench with multifunctional shelf
    • winter tires on steel rim 17 inch
    • Driver's seat adjustable (height, inclination, longitudinal direction)
    • Suspension, trapezoidal spring on rear axle
    • Manual six-speed gearbox
    • Paint:  RAL white
    • 180 hp, diesel engine, 4 cylinders
    • Seat covers textile, breathable, anthracite
    • Tank, diesel 90 l
    • Iveco Daily C70
    • AdBlue® tank 25 l
    • Electronic stability program (ESP), Start-up assistant (AAS),
    • AM/FM and DAB antenna in right-hand wing mirror
    • Mirrors for vehicle width 2.35 m
    • Lane-departure warning
    • Digital tachograph without calibration
    • Electrically adjustable and heated door mirrors
    • electric windows
    • Electronic immobilizer
    • Elimination of cabin back wall
    • Height adjustable steering wheel
    • Driver air bag
    • Chassis with ladder frame
    • speed limitation device 110 km / h
    • Brake assist, hydraulic
    • grey bumper of PVC
    • Sensor for oil level monitoring
    • Daytime Running Light
    • Central locking with remote control
    • Body partly galvanized

Internal Space

  • Living area
    • All furniture parts in solid wood,
    • LED lights in the living room
    • PVC flooring
    • Open back wall of the cab
    • Front door, lockable
    • Coat hooks
    • Mirror

Accessories

Body

  • Body general
  • Body Horse department
    • Selection barrier in front of loading ramp
    • Stop board before loading ramp instead cordon, pivotable
    • Selection partition
    • Partition (L) of aluminum elox. sliding, with transparent PVC curtain
    • Further equipment options
    • Anchoring rope with panic hook (set)
    • Excrement slide
    • LED-working illumination for the vicinity of the loading flap.
    • LED-Light in horse area, additional
    • Calming illumination (blue)
    • Kick protection between partition hangers
    • Temperature control  (according to regulation EG 1/2005)
    • Animal transport report
    • Wear mat for each horse place
    • Video monitoring incl. reversing camera
    • Electric winch
  • Tack room
    • Bag net additional
    • Additional shelf
    • Shelf-system with storage boxes in tack room
    • Saddle rack additional
    • Anodized aluminum cabinet, ceiling height in high tack room
    • Snaffle hooks, additional

Chassis

  • Chassis
    • Selection front passenger seat
    • Passenger seat rotatable
    • Seat, Passenger, Comfort(3-way adjustable, armrest, lumbar support)
    • Bench, deleted
    • Selection tyres
    • Winter tires / M + S tires
    • Selection driver's seat
    • Driver's seat rotatable
    • Seat, driver luxury with armrest, lumbar support, hydraulically
    • Selection suspension chassis
    • Air-Suspension (rear axle)
    • Selectrion gears
    • Transmission, automatic Hi-Matic, 8 speed gearbox
    • Selection painting
    • Paint, complete in metallic-colors (except PVC parts of the chassis)
    • Paint, complete in RAL-Colors
    • Paint of plastic parts (cab), metallic-colors
    • Selection motorisation
    • Surcharge 205 hp
    • Selection seat covers
    • Seat covers Skai leather, per seat
    • Selection tank size
    • Tank, diesel 117 L
    • Further equipment options
    • Airbag, passenger with belt tensioner
    • Trailer coupling (ball head), rigid
    • Battery reinforced (210 Ah)
    • Bluetooth touch screen radio with CD
    • Differential lock at rear axle
    • Floor mat (rubber)
    • Floor mats (driver's cab)
    • Air conditioning, automatic, with pollen filter and outside temperatur
    • Air conditioning, manual
    • Fog lights with static cornering light
    • Secondary drive
    • Radio / RDS, CD, 7 "monitor, MP3 USB, Bluetooth, navigation with
    • Wheel covers, stainless steel
    • Reversing warning, acoustic
    • Cruise control
    • Reinforced generator 210 Ah

Internal Space

  • Living area
    • Boiler, hot water, 15l
    • Window for exterior door,370x500mm, erectable, incl.rollo+mosquito net
    • Window, vertically sliding, without grille in external door
    • Door mat with emblem Böckmann
    • Stool, foldable
    • Jack cabinet above tack room
    • Folding table at partition wall
    • Cupboard under the ceiling, about 550 wide
    • Cabinet with 1 wardrobe, 2 drawers and 1 folding seat
    • Seat, 2 persons, seat belt for each person, with upholstery,
    • Seat, 3 persons, seat belt for each person, with upholstery,
    • Table, mobile, foldable, oval shape, approx. 500 x 700mm
    • Curtain passage
    • Apartment furnishings can be individually designed. Please Contact us!
  • Kitchen
    • Ceran Cooking hob 230 V
    • Kitchen block: Base cabinet with worktop approx. 500 x 500 X 900, with
    • Refrigerator (12V)
    • Microwave 230 V
    • Sink, stainless steel with faucet and electric pump
  • Bathroom
    • Shower with cover approx. 600 x 800, with boiler and shower set,
    • Toilet, fixed with electric water purge and cassette
    • Toilet, mobile "Porta Potti Excellence"
    • Washbasin with pump and 20l water canister, cold water system
  • Sleeping
    • Mattress in alcove (incl. Ladder)

Other

  • Electrical system
    • Rooftop air conditioning
  • Heating
    • Diesel auxiliary heating D2, 12 / 24 V, max. 2000 watts
  • Paintwork
    • Lettering Horses and Dressage and right
    • Lettering Horses and Jumper left and right
    • Lettering Horses and mare with foal left and right
    • Lettering Horses and looking horse left and right
    • Lettering "2-Horse-Heads" left and right
  • Accessories
