Big Equipe S 5.35.18
Price on request

Characteristics

Number of animals
5 Horses
Family
Equipe family, 18000 kg
Number of sleeping places
5
Some competitions are already won on the way to the event: The Big Equipe S with a large horse compartment for up to five horses, spacious living quarters and XXL drivers cab is really impressive and will also spark your enthusiasm. Unsurpassed space and comfort. What more can you ask?

Technical data

Base
Number of animals Number of animals
5 Horses
Apartments Apartments
Royal 350 cm
Bathroom Bathroom
Small bathroom with toilet
Weight
Total weight Total weight
18000 kg
Payload Payload
3915 kg
External dimensions
Total length Total length
10860 mm
Total width Total width
2550 mm
Total height Total height
4000 mm
Internal dimensions
Interior length Interior length
4860 mm
Interior width Interior width
2440 mm
Interior height Interior height
2450 mm

Standard features

Body

Chassis

  • Chassis
    • Selection driver's seat
      • Driver seat standard
    • SES
      • Mercedes-Benz Actros Neu 18 L
      • Tank 630 l
      • AdBlue® tank 60 l
      • 240 kW / 326 hp
      • 2x12V/170 Ah batteries
      • PowerShift 3 transmission
      • Front spring, 7.5 t, 2-leaf
      • Trailer coupling
      • trailer socket. 24-V, 15 pole
      • Front mirror, heatable
      • main mirror electrically adjustable, on drivers side
      • Wide angle mirror heatable
      • Extended central locking systems
      • Cruisecontrol
      • Functional seat for passenger
      • Radio with USB port
      • Multifunction steering wheel
      • electric windows
      • Air Conditioning

Internal Space

  • Living area
    • Selection ladder to entrance
      • Extension ladder at the front door with latch
    • SES
      • All furnitures in solid construction with safety catches
      • PVC flooring
      • Topsleeper, insulated, lined with carpet, incl mattress and ladder
      • Walls panelled with laminated plastic sheeting
      • Lockable entrance door with 3-point closure
      • Separation to horse area by 25mm anodized.Aluminium Double web profile
      • Cabinet row: 1 Jack closet, 1 filing cabinet, several wall cabinets
      • Two opposing benches for 4 persons with seat cushion
      • Lowerable table
      • Mirror
      • 4 coat hooks in the entrance area
      • Door mat with emblem Böckmann
      • Living room window above the bench, 900x600 mm, multifunctional,
  • Kitchen
    • SES
      • Kitchenette with work surface
      • 230 V sockets (2x) above kitchenette
      • cabinet with drawer and towel rail under the work surface
      • Living room window above kitchen, multi-functional,
      • Ppotlights above kitchenette
      • Sink with tab
  • Bathroom
  • Sleeping
  • Lighting
    • SES
      • 6 halogen spotlights in the ceiling, 1 radiator (reading lamp) in

Other

Accessories

Body

Chassis

  • Chassis
    • Selection driver's seat
      • Pilot's seat, with armrests, adjustable, rotatable

Internal Space

Other

  • Electrical system
    • Selection electricity
      • Electrical basic package 2
      • Electrical basic package 3
    • Further equipment options
      • AGM auxiliary battery 200 AH
      • Hydraulic package
      • 3,5 - 4 KW generator (diesel generator)
      • 4800W generator (diesel generator)
  • Heating
  • Paintwork
    • Selection painting
      • Paint, complete in metallic-colors (except PVC parts of the chassis)
      • Paint, complete in RAL-Colors
      • Paint of plastic parts (cab), metallic-colors
      • Paint of plastic parts (cab), RAL colors
    • Further equipment options
      • Lettering "2-Horse-Heads" left and right
  • Water / wastewater
    • Selection waste water tank
      • Waste tank 300 l (Surcharge)
    • Selection fresh water tank
      • Fresh water tank 300 l (Surcharge)
    • Further equipment options
      • Warm water, 15 l
  • Accessories
